AIRSUSTECH 2B4.5X1 AIR SPRING Cross other OEM:
| Cross Number |
| AIRSUSTECH Part Number:2B4.5X1 | Continental ContiTech: FS 44-5 DI G3/8 CR | Norgren Part Number:M/31041 / | Firestone Part Number:W01-R58-4050, |
| Dunlop UK NP901056050505 | Continental ContiTech: FS 44-5 DI CR / FS44- -5DICR / FS445DICR | | |
| DUNLOP Part Number:SP 2334 | ContiTech Bellows: FS 444-55 / FS445 | AIRSUSTECH Part Number:2B4.5X1 | Firestone Part Number:WO1R584050, |
| Dunlop:41⁄2 x 1 | | | |
| DUNLOP Part Number:SP2334 | Continental FS 44-5 DI G 3/8 CR | Norgren Part Number:M 31041／ | Firestone Part Number:WO1-R58-4050 |
| Dunlop Bellows Number :41⁄2 x 1 | | | |
| Dunlop FR: 4/x1 SP2334 | Continental FS44-5 DI G 3/8 CR | AIRSUSTECH Part Number:2B4.5X1 | : W01-R58- -4050 1 W01 R58 4050 1 W01R584050 |
| | Contitech Part Number:FS 44-5 DI G 3/8 CR | | Firestone model: 4 1/2” x1 |
| European ContiTech: FS 44- -5 DI CR G3/8 M6 | Continental FS44-5 DI G 3/8 | Norgren Part Number:M31041 | |
| European ContiTech: FS 44-5 70205 | Contitech Part Number:FS44-5 DI G 3/8 CR | | Nominal diameter 0 (inch) x convolution: 4 1/2” x1 |
| European ContiTech: FS 44-5 DI CR 70205 | Contitech Part Number:70205, | | : 9109400 |
| European ContiTech: FS44-5 G3/ 8 M6 | Contitech Part Number:FS44-5 DI G 3/8 | | |
| European ContiTech: FS44 -5 DICRG3/ 8 | Contitech Part Number:FS44-5DIG3/8CR | Firestone Part Number:W01R584050, | |
AIRSUSTECH 2B4.5X1 Industrial Single Convoluted Air Spring Specifications in inch:
| Compressed height | 1.97" | Inlet type | Metric |
| | | | |
| Maximum deployment height | 3.54" | Air inlet | 3/8" |
| | | | |
| The maximum diameter | 4.92" | series | D |
| | | | |
| Maximum inflation pressure | 120 psi | lowest temperature | -22°F |
| | | | |
| Maximum stroke | 1.57" | Maximum temperature | 194 degrees F |
| | | | |
| weight | 1 pound. | Bellows type | Single twist |
41⁄2 x 1 Dunlop Air Spring Specifications in mm:
❶Nut/blind nut
Nut length: 13.5 mm
Number of screws on the top cover: 4
Number of bottom cover screws: 4 pcs
Top cover plate screw (nut) tooth: M6
Top cover screw center distance: 93mm
Screw (nut) teeth of the bottom cover plate: M6
Center distance of bottom cover plate screw: 93mm
❷ Air hole/air inlet/air connector
Air hole/air inlet: G3/8
❸ Cover
Top cover diameter: 110 mm
Diameter of bottom cover: 110 mm
❹Rubber bellows
Max OD of rubber bellows:125mm
Natural diameter of rubber bellows: 120mm
Natural height of rubber bellows: 115 mm
❺ Buffer block/buffer block
Unbuffered block
❻ Waist ring/waist ring
Strap ring: no strap ring
